Concrete fence posts, grape, trellis

Home / Fence and mesh posts / Concrete posts

Price of concrete pillars ➤

The most profitable type of poles

In terms of price-strength ratio, the primacy belongs to concrete pillars. Price for poles in PRICE
Want to save? Concrete poles are the best investment you can make.
That is why concrete pillars are so widespread.

Concrete poles will be shipped from a warehouse in the Dnieper. If you need to buy poles in Kyiv, Vinnitsa, Lviv, Odessa, Kharkov or other cities, then we will either deliver these or offer them from a production facility closer to you.

Prices for concrete poles are indicated in our price list with VAT.
Payment through the cash desk of the bank or by bank transfer.

Range of standard concrete poles

• Concrete column 80x90x2200 mm for a chain-link fence;
• Concrete grape pole 80x90x2500;
• Concrete grape pole 80x90x2700;
• Concrete trellis starting post 110x110x3000;
• Concrete trellis pole 80x90x3500;
• Concrete pillar 80x90x4000 for hail protection mesh;
• Concrete pillar 80x90x4500 for protection against hail.

Production of columns for a fence by the special order is possible.

Benefits of using concrete pillars

Concrete posts for fences

• Low price ;
• Easy to install;
• Does not require painting;
• Do not rot or deteriorate;
• Not interested in metal detectors

Grape poles (grape stake) 2.5 - 3 m:

• simple installation procedure;
• do not require constant repair;
• do not create a beneficial environment for microorganisms harmful to the vine;
• long service life;
• withstand heavy loads.

Trellis poles for the garden 3.5 - 4.5 m:

• mechanization of garden care processes;
• increasing the density of planting trees;
• increasing the yield of fruit crops;
• reducing the area of the garden without reducing the amount of harvest;
• prevent damage to trees;
• the probability of breakage of branches from the wind, other natural and natural factors is reduced.

If you decide to buy trellis poles, pay attention to the special high-carbon trellis wire.

Specifications of concrete pillars

* - the number of holes and their location according to customer requirements. Production of 5 meter length is possible .

Concrete poles to protect crops from hail

PE "Metizy-94" offers to buy poles with a height of 3500-5000 mm for hail protection mesh tension.

They are specially designed to protect the vineyard and orchard from hail and other natural disasters - the length is over 3.5 m, the material is M300 concrete, which is designed for constant long-term loads, they are reliably reinforced with an 8 mm reinforcement frame.

Installing nets on them will provide guaranteed protection for your crop.

IT'S IMPORTANT TO KNOW! When installing, a hole for a pole must be made below the freezing level of the ground. And the reason for this is the property of the soil during freezing. The soil increases in volume, this effect is called "soil heaving". Swelling occurs due to the presence of moisture. The map of soil freezing in the figure on the left will help you.

As you can see, in Odessa this figure is 80 cm, in the Dnieper and Zaporozhye, Kyiv - 100, Kharkov - 120.

If the foundation of the fence is flooded within freezing limits, then at low temperatures the earth will expand and push the foundation of the fence up. In spring, during thawing, reverse processes occur, the soil sags, deforming the foundation of the fence.

When the foundation of the fence lies below the freezing level, it is also exposed to heaving, but tangentially, which significantly reduces the load.

To reduce the impact of low temperatures on the stability of the installation of the fence post, the forces of frost heaving, the bottom of the pit is lined with crushed stone (gravel, sand), the so-called backfilling of the pillars, in addition, it performs the functions of drainage.

The depth of the pit for mounting fence posts should be approximately 1/3 of its length, i.e. the higher the post, the deeper it is dug.

Technologies for the production of concrete pillars for fences and trellises

Production technology - vibrocasting method using M-250 or M-300 concrete. To impart high water-resistant and frost-resistant qualities, plasticizer additives are used.
Main stages: preparation of molds, mixture preparation, molding on a vibrating table, holding (drying) of pillars in molds, stripping products, packaging and storage.

In the steaming chambers, the poles are subjected to hydrothermal treatment, that is, steaming. Steaming accelerates hardening, increases strength by 10-15%.
Concrete columns up to 3 meters high are reinforced with VR-1 wire with a diameter of 4 mm or 5 mm.

Concrete pillars with a height of 3 m and above are reinforced with a metal frame made of 6-8 mm wire, every 40 cm there are rings of 5 mm wire along the frame . Fittings for the production of concrete pillars in the photo on the left.

For each batch, a concrete test report is issued with data on compressive strength, tests for frost resistance, water resistance.

There are 16 poles in a pack. The maximum weight of one column is 83 kg. If you will make a batch to order, then do not rush us. Concrete gains strength over the years. It takes 28 days in the warm season to gain strength acceptable for transportation, and longer in winter. If you ship it earlier, then along the way the poles may burst from vibration. Keep this in mind if someone suggests faster production.
