Technical characteristics of the anchor for the installation of a fidget and lining Zhachok.
Dimensions:
- Anchor diameter 6 mm.
- Anchor length 65 mm.
- Cap diameter 15 mm.
The maximum thickness of the attached material is 5 mm.
Material: high carbon steel.
Corrosion protection: galvanized.
The thickness of zinc is 3-5 microns.
It consists of two parts: a stud and a protruding wedge.
The stud consists of a head with a hole and a wedge.
The metal expansion anchor is designed for fast fastening.
The wide cap increases the degree of fastening reliability.
The anchor is not intended for reusable use. Once hammered, the anchor can either be sawn off or pulled out with a force of 0.5 kN (50 kg-force).
Installation instructions
Fastening is carried out in three stages:
- drill holes with a 6 mm drill;
- insert the anchor into the hole by passing it through the mounting hole of the fixed part;
- wedge the anchor with a hammer along the wedge until it completely enters the hole in the head of the stud.
The wedge enters the wide part of the dowel and wedges it. As a result, there is a spacer and reliable fixation of the anchor in concrete, brick or cinder block.
Even in cinder block or hollow brick, this anchor can be fixed, because the expansion begins at the very base of the head.
Scope of application
The main advantage of the anchor for the installation of barbed obstacles is that no welding is required. In extreme cases, the anchor holes can be made manually.
The metal expansion anchor is ideal for installing egoza and barbed wire brackets. In this case, trapezoidal brackets from the corner are used, which are also available in our warehouse. For fixing semicircular brackets, an additional base plate is needed.
A metal wedge anchor is optionally supplied with the . For fastening, the anchor is hammered into the holes already provided.
